• LF Variant: 12000 mm × 2576 mm × 3470 mm
• HF Variant: 12000 mm × 2576 mm × 3508 mm
• Wheelbase: 6320 mm (LF), 6200 mm (HF)
• Floor Height: 380 mm (LF), 900 mm (HF)
• GVW: 18,500 kg
• Structure:
– LF: Corrosion-resistant monocoque with high-strength steel
– HF: Ladder frame chassis with high-strength steel
• Side Panels: Aluminium, optional stretched steel
• Passenger Doors: Automatic (front & middle)
• Door Types: In-Swing, Out-Swing, Jack-Knife (optional)
• Emergency Exits: Yes
• Wheelchair Ramp: Pneumatic (manual optional)

• Capacity: 72 passengers (as per CMVR)
• Seat Type: Reclining seats with comfortable legroom
• Passenger Comfort: USB charging, vehicle tracking, quiet cabin

• Tyres: 295/80 R22.5 Radial Tubeless (Front & Rear)
• Suspension: Front & Rear Air Suspension with ECAS (optional)
• Kneeling System: Available (optional)

• Traction Motor: Permanent Magnet Synchronous Motor, 250 kW Max Power
• Battery Type: Advanced Li-ion Chemistry
• Charging: CCS2 Plug-in Fast Charging
• Regenerative Braking: Yes
• Daily Operational Range: 300 km
• Max Speed: 80 kmph

• Brakes: All Disc Brakes (Drum optional)
• Safety Systems:
– EBS and ABS for stability
– FDSS (Fire Detection & Suppression System)
– High-temperature battery cut-off
– Surveillance cameras and VTS
– HV safety: surge, short circuit, overload protection, insulation monitoring, interlock system
– IM and IL safety compliance

• Steering: Electrically driven + Hydraulic power assisted with tilt & telescopic mechanism
• HVAC: Yes (heating optional)

• 12 m platform with LF and HF options
• 300 km range with CCS2 fast charging
• Zero-emission, noise-free operation

• Reclining seats, USB charging, AC louvers
• Pneumatic wheelchair ramp and kneeling system
• Quiet cabin with vehicle tracking

• EBS + ABS with full disc brakes
• FDSS, thermal cut-off, and HV insulation monitoring
• AIS-052 compliant body with IM/IL safety standards
