• GVM: 13,500 kg
• Overall length: 8900 mm
• Overall width: 2465 mm
• Overall height: 2930 mm
• Floor height: 650–900 mm
• Seating capacity: 24–35 + Driver

• Monocoque chassis with dual in‑wheel drive
• Maximum power: 180 kW
• Maximum torque: 800 Nm
• Transmission: Automatic
• Brake system: Disc brakes with ABS/EBS
• Steering: Power‑assisted
• Suspension: Front and rear air suspension
• Tyres: 255/70 R22.5

• Lithium Iron Phosphate (LFP) battery
• Range: Up to 180 km per charge
• Charging time: 2–3 hours (fast charging)
• Charging mode: AC charging ≤ 80 kW
• Input voltage: 415 V AC (3‑phase)
• Input current: 300 A
• Cable length: 4.5 m
• Charger dimensions: 750 × 800 × 2050 mm
• Charger net weight: ~395 kg
• Housing protection: IP55
• Battery cooling system: Integrated
• Battery safety: Automatic fire extinguisher, leakage sensors, temperature sensors
• Battery management system: Optimal performance ensured

• Max speed: 70 km/h (with speed limiting device)
• Acceleration: 1.72 m/s² (0–60 km/h)
• Electrical regeneration: Available
• Low energy consumption per km

• AIS 052 compliant body
• Air conditioner: Available
• Door: Single door, manually openable
• UBS II standard compliance

• Short circuit protection
• Over‑temperature protection
• Fire‑proof batteries and electric powertrain
• Automatic fire extinguisher in battery pack
• Electricity leakage sensors for batteries and high‑tension wires

• ABS/EBS disc braking system
• Fire‑proof batteries with automatic fire extinguisher
• CCTV surveillance and Intelligent Tracking System (ITS)
• Real‑time tracking enabled
• Medical kit, glass hammers, fire extinguisher onboard
• UBS II standard compliance

• Spacious seating for 24–35 passengers
• Air suspension for smooth ride
• Air conditioning available
• Low NVH levels due to monocoque chassis
• Manually openable door for safety

• Dual in‑wheel motor solution with regenerative braking (30% recovery)
• Fast charging (2–3 hours full charge)
• Minimal maintenance due to electric powertrain
• ECO mode switch for enhanced mileage
• Significant savings on charging station investment & maintenance

• ITS enabled (real‑time tracking, video surveillance)
• Telematics and fleet management solutions
• Multi‑modal transport integration for smart cities

• Ideal for metro feeder, staff transport, and congested urban routes
• Longer range (up to 180 km) compared to Olectra v2
• Future‑ready electric mobility solution for smart cities
• Strong resale value with Olectra’s engineering reliability
