Lynx Max
Rs. 21 Lakhs
Specifications & Features
Specifications
Features
Powertrain & Fuel System
• Engine: H‑series 4‑cylinder Turbo Charged & Aftercooled DI
• Displacement: 3.84 L
• Power Output: 110 kW
• Torque: 450 Nm
• Emission Norm: BS‑VI Phase 2
• Transmission: 6‑speed Overdrive
• Clutch: Single‑plate diaphragm type with air‑assisted hydraulic actuation
• Shifting Mechanism: Cable shift system
• Fuel Type: Diesel
• Fuel Tank: 185 L
• DEF Tank: 24 L
• Mileage (Certified): ~6.5–7.5 km/l (mixed duty cycle)
• Displacement: 3.84 L
• Power Output: 110 kW
• Torque: 450 Nm
• Emission Norm: BS‑VI Phase 2
• Transmission: 6‑speed Overdrive
• Clutch: Single‑plate diaphragm type with air‑assisted hydraulic actuation
• Shifting Mechanism: Cable shift system
• Fuel Type: Diesel
• Fuel Tank: 185 L
• DEF Tank: 24 L
• Mileage (Certified): ~6.5–7.5 km/l (mixed duty cycle)
Suspension & Structure
• Front Suspension: Parabolic leaf spring
• Rear Suspension: Parabolic leaf spring
• Chassis: Ladder frame
• Cabin: OEM-built bus body
• Rear Suspension: Parabolic leaf spring
• Chassis: Ladder frame
• Cabin: OEM-built bus body
Electricals & Telematics
• System Voltage: 12 V (Non‑AC) / 24 V (AC)
• Battery: 130 Ah (Non‑AC) / 150 Ah (AC)
• Alternator: 90 A (Non‑AC) / 150 A (AC)
• AC Compressor: Engine-mounted TM 43 (optional)
• Driver Info Display: Standard
• Connectivity: Not equipped with telematics
• Battery: 130 Ah (Non‑AC) / 150 Ah (AC)
• Alternator: 90 A (Non‑AC) / 150 A (AC)
• AC Compressor: Engine-mounted TM 43 (optional)
• Driver Info Display: Standard
• Connectivity: Not equipped with telematics
Dimensions & Capacity
• Wheelbase: 4,900 mm / 5,200 mm
• Front Overhang: 2,020 mm
• Overall Width: 2,590 mm
• Overall Length: 10,340 mm
• GVW: 11,100 kg
• Turning Circle Diameter: ~20.5 m
• Front Overhang: 2,020 mm
• Overall Width: 2,590 mm
• Overall Length: 10,340 mm
• GVW: 11,100 kg
• Turning Circle Diameter: ~20.5 m
Seating Layouts
• 3×2 HHR: 50+D / 55+D
