1 5T
Rs. 9.5 – 12.5 Lakh
Specifications & Features
Specifications
Features
Dimensions, weight and body
• Vehicle L × W × H: 4610 × 1600 × 1850 mm
• Wheelbase: 2900 mm
• Turning radius: 5.5 m
• GVW: 2510 kg
• Payload (tech spec): 1300 kg
• Vehicle category: N1
• Chassis: Ladder frame
• Seating capacity: D + 1
• Deck length: 9 ft (best‑in‑class)
• Battery mounting: Centrally mounted
• Wheelbase: 2900 mm
• Turning radius: 5.5 m
• GVW: 2510 kg
• Payload (tech spec): 1300 kg
• Vehicle category: N1
• Chassis: Ladder frame
• Seating capacity: D + 1
• Deck length: 9 ft (best‑in‑class)
• Battery mounting: Centrally mounted
Container specifications
• Body type: Sturdy MS/AL body
• External dimensions: 2750 × 1750 × 1956 mm
• Internal dimensions: 2687 × 1692 × 1855 mm
• Volume: 8.44 m³ / 300 ft³
• Branding space: 13.01 ft² available area
• External dimensions: 2750 × 1750 × 1956 mm
• Internal dimensions: 2687 × 1692 × 1855 mm
• Volume: 8.44 m³ / 300 ft³
• Branding space: 13.01 ft² available area
Tyres, steering, suspension, brakes
• Tyre size: 175R 14LT (14‑inch)
• Steering: Rack & pinion, electrically assisted
• Front suspension: MacPherson independent
• Rear suspension: Longitudinal leaf spring
• Brakes: Front disc, rear drum
• Steering: Rack & pinion, electrically assisted
• Front suspension: MacPherson independent
• Rear suspension: Longitudinal leaf spring
• Brakes: Front disc, rear drum
Powertrain and performance
• Battery type: Lithium Ferrous Phosphate (LFP)
• Battery capacity: 32 kWh
• Operating voltage: 307 V
• Peak power: 60 kW
• Peak torque: 220 Nm
• Max speed: 70 km/h
• Range (single charge): 180 km*
• Gradeability: 18%
• Hill‑hold assist: Yes
• Battery capacity: 32 kWh
• Operating voltage: 307 V
• Peak power: 60 kW
• Peak torque: 220 Nm
• Max speed: 70 km/h
• Range (single charge): 180 km*
• Gradeability: 18%
• Hill‑hold assist: Yes
Charging
• Charging mode: Single‑phase AC (wall‑mounted)
• Charging time: 4 hours
• Input voltage: 240 V ±10%, 50 Hz ±5%
• Input current: 32 A (max)
• Charging time: 4 hours
• Input voltage: 240 V ±10%, 50 Hz ±5%
• Input current: 32 A (max)
Warranty
• Vehicle warranty: 3 years or 1,65,000 km (whichever is earlier)
• Battery warranty: 6 years or 1,65,000 km (whichever is earlier)
Range is as per standard/applicable driving cycle. Payload in product highlights states “class‑leading 1500 kg”, while technical specification lists 1300 kg.
• Battery warranty: 6 years or 1,65,000 km (whichever is earlier)
Range is as per standard/applicable driving cycle. Payload in product highlights states “class‑leading 1500 kg”, while technical specification lists 1300 kg.
