12M
Rs. 2.35 – 2.95 Crore
Specifications & Features
Specifications
Features
Dimensions & Build
• Length × Width × Height: 12000 mm × 2600 mm × 3600 mm
• Wheelbase: 6200 mm
• GVW: 19,500 kg
• Structure: Ladder chassis with modular architecture
• Floor Type: Standard floor with full standing height
• Accessibility: Handicap-friendly version available
• Wheelbase: 6200 mm
• GVW: 19,500 kg
• Structure: Ladder chassis with modular architecture
• Floor Type: Standard floor with full standing height
• Accessibility: Handicap-friendly version available
Seating & Layout
• D + 43 (2×2)
• D + 54 (3×2)
• Interior: Climate-controlled, low NVH, bacterial filtration system
• Wheelchair Access: Yes
• D + 54 (3×2)
• Interior: Climate-controlled, low NVH, bacterial filtration system
• Wheelchair Access: Yes
Tyres & Suspension
• Tyre Type: Tubeless Radial
• Tyre Size: 295/80 R22.5
• Suspension:
– Standard: Air Suspension
– Optional: Electronically Controlled Air Suspension (ECAS)
• Steering: Electro-Hydraulic Power Steering with Tilt & Telescopic Mechanism
• Tyre Size: 295/80 R22.5
• Suspension:
– Standard: Air Suspension
– Optional: Electronically Controlled Air Suspension (ECAS)
• Steering: Electro-Hydraulic Power Steering with Tilt & Telescopic Mechanism
Powertrain & Battery
• Motor Type: PMSM (Permanent Magnet Synchronous Motor)
• Max Power: 240 kW
• Max Torque: 3000 Nm
• Battery Type: Lithium Ferrous Phosphate (LFP)
• Battery Capacity: 300 kWh
• Operating Voltage: 660 V
• Charging: CCS2 Dual-Gun Fast Charging
• Charger Options: 180 kW | 240 kW (Single Gun)
• Charging Time: 3.5 hrs | 2.5 hrs
• Range: 250 km (standard driving cycle)
• Gradeability: 17%
• Max Speed: 80 kmph
• Max Power: 240 kW
• Max Torque: 3000 Nm
• Battery Type: Lithium Ferrous Phosphate (LFP)
• Battery Capacity: 300 kWh
• Operating Voltage: 660 V
• Charging: CCS2 Dual-Gun Fast Charging
• Charger Options: 180 kW | 240 kW (Single Gun)
• Charging Time: 3.5 hrs | 2.5 hrs
• Range: 250 km (standard driving cycle)
• Gradeability: 17%
• Max Speed: 80 kmph
Brakes & Safety
• Brakes:
– Front: Disc Brakes
– Rear: Drum Brakes
• Safety Systems:
– ADAS (Advanced Driver Assistance System)
– Liquid-cooled battery
– Regenerative braking
– Sturdy axles
– Stainless steel monocoque chassis
– Front: Disc Brakes
– Rear: Drum Brakes
• Safety Systems:
– ADAS (Advanced Driver Assistance System)
– Liquid-cooled battery
– Regenerative braking
– Sturdy axles
– Stainless steel monocoque chassis
Climate Control & Comfort
• HVAC: AC with optional demister
• Type: Service Unit + Free Flow
• Capacity: 32 kW
• Interior: Full standing height, ergonomic cockpit, integrated dashboard
• Type: Service Unit + Free Flow
• Capacity: 32 kW
• Interior: Full standing height, ergonomic cockpit, integrated dashboard
12M Comparison with Similar Buses
| Model |
 EKA Mobility Coach |
 EKA Mobility LF |
EKA Mobility 12M |
 EKA Mobility 9M |
|---|---|---|---|---|
| Rating | 4.5 ⭐ 100+ Reviews | 4.5 ⭐ 100+ Reviews | 4.5 ⭐ 100+ Reviews | 4.5 ⭐ 100+ Reviews |
| Price Range | 2.65 – 3.25 Crore | 2.25 – 2.85 Crore | 2.35 – 2.95 Crore | 1.85 – 2.35 Crore |
| Fuel Type | Electric | Electric | Electric | Electric |
| Model Year | 2025 | 2025 | 2025 | 2025 |
| Vehicle Type | New | New | New | New |
| Action | Compare | Compare | Compare | Compare |
